Fibreglass Rods

Product information

Made for the way an Ultimate is used.

Replacement fibreglass rods

Choose the diameter and supplied length from the dropdown. The same rod can suit several positions on the tent diagrams; position letters are a fitting guide, not separate part numbers.

• Rods are sold individually.

• Only 8 mm rods are supplied with two black ends. Other diameters are supplied without black ends.

• Poles may need to be trimmed to suit your camper, including differences caused by weathering or canvas shrinkage. Check the required finished length against your existing rod and tent before trimming.

Tent position guide

180 tent: 13 mm × 1650 mm can be trimmed for positions A and D; 8 mm × 2300 mm for position C; 8 mm × 1950 mm for positions E and F. For the 10 mm × 1950 mm rod shown at position B, select that size from this same dropdown.

360 tent: 13 mm × 1650 mm for position A; 8 mm × 1950 mm can be trimmed for positions B and C.

Standard tent: 10 mm × 1230 mm for position A; 10 mm × 1950 mm for position B; 10 mm × 1650 mm for position C. The 6 mm × 1950 mm eyebrow rod suits MK1 position D.

The diagrams show where the rods fit. Supplied rods may be longer than the fitted measurements shown. Contact our sales team if you are unsure which diameter or length to order.
